Maestrini Bronze Body Ball Valve (2-1/2" BSP Female)
Description
The Maestrini 405729 ball valve body is constructed from bronze with a stainless steel handle. This ball valve is suitable for hot water, steam, gasoline, fuel, oil, gas oil, kerosene and compressed air. The bronze body ball valve has a 2.5" threaded BSP Female port each end as well as a lever handle on top which requires a 1/4 turn. The stainless lever handle comes with a rubber grip cover.
Depending on the application and installation requirements, these bronze body ball valves may not be suitable for below waterline applications.
All fittings used for below the waterline applications must be correctly fitted and bonded so as to minimise the risk of electrolytic action
| Height | 171mm |
| Length | 142mm, Lever: 200mm |
| Temperature Range | -10°C to +120°C |
| Brand | Maestrini |
| Thread Gender | Female |
| Valve Design | Ball Valve |
| Country of Origin | Italy |
| Construction | Bronze Body with Chrome Plated Brass Ball and Stainless Steel Handle |
| Dimensions | Bronze Body (CC491K) with Chrome Plated Brass Ball (CW617), Stainless Steel Handle (AST430) with Non-Slip Grip, PTFE Ball Sealing Gaskets and Brass Valve Shaft & Packing Body (CW617) |
| Maximum Pressure | 500 PSI |
| Thread Size | 2-1/2" BSP Female |
