MARINE SANITATION HOSE - 19mm ID
Description
Light-weight and flexible, specially designed as effluent hose for leisure marine toilet systems, where low permeation to odour is required.
Specification:
Cover: White, smooth EPDM rubber compound, particularly resistant to abrasion, heat and weathering
Tube: Black, antistatic (R ‹ 1 MO/m), Smooth EPDM rubber compound.
Reinforcement: Synthetic textile fabric and embedded steel wire helix.
Temperature Range: -40°C to +100°C.
Suction: Max. 0,8 bar (600 mm Hg).
Tolerance: RMA steel mandrel.
On inside diameter: ± 0.79 mm.
Length tolerance: ± 1%.
Coil Length: 10 Metre.
- I.D mm: 19
- O.D mm: 31
- Working Pressure: 1.0 (MPs), 150 (psi), 10 (bar)
- Burst Pressure: 3.0 (MPs), 450 (psi), 30 (bar)
- Bend Radius mm: 110
